Larger Size

Introduction | Key Features | Specs | Audio Demo | Order | XEditor | Download

Oscillators

- 3 Oscillators with Waveforms: Saw, Square, Triangle, Variable Shape Saw-Sqr, Tri-Sqr, Stepped Sqr
- Oscillator special features: Hard sync, Phase sync, Phase adjustment, Square PW, Shape Modulation, Detune, FM, Analog Drift
- 4 types of noise: White, Pink, Red, C64 (pitched)
- 1 Analog Ring modulator

Paraphonic Playability

- True 2-voice paraphonic (Duophonic) mode with dedicated envelopes per oscillator. (Voice1=Oscillator1, Voice2=Oscillator 2/3 )

Filter

- 1 Multimode VCF with 6 filter types and 3 selectable slopes: 12,18, 24dB (Lowpass , Highpass, Bandpass, Notch, 18LP>6HP, 12LP>6HP)
- VCF self-oscillation with Sinus, Triangle and Clipped Triangle wave in different modes
- Filter FM via Oscillator1 (audio rate modulation of filter freq)
- Precise filter keytracking including: note pitch, portamento and pitchbend signal

Modulations

- 3 LFOs with 6 Waveforms (Sin, Tri, Saw, Sqr, S&H, S&Glide)
- LFO Features: Sync, Reset, Freq Range= 0 - 100Hz
- LFO1 and 3 have 6 easy access mod targets independent from mod matrix
- 3 Envelope Generators: Amp, Filter, Mod (6-stage DAHDSR from 1mS to 30S)
- 4 Envelope Styles (Analog RC1, RC2, Exponential, Digital Linear)
- 6 Envelope Trigger modes (Always, Legato, Analog1, Analog2, LFO2 S&H, #FootP)
- Loop option for all envelopes
- 8-Slot Modulation Matrix (up to 33 mod sources and 50 mod targets)
- CV Input as mod source

Effects and Main bus

- 4 Types Analog Distortion (light, dirty, harsh, massive)
- 24-bit Stereo Digital FX (Room, Hall, Cathedral, Gated, Plate, Delay, Delay+Reverb, Ping Pong Delay) with modulatable parameters
- Feedback loop via external audio input
- Stereo output with balance control
- Low noise and high quality VCAs for amplitude and balance

Arpeggiator and Sequencer

- Arpeggiator with gate adjustment, various spans and 15 clock divisions (syncable to MIDI clock)
- 16x4 step sequencer per program (Note, Velocity, AUX Track1, AUX Track2)
- Sequencer features: Note Slide, Slew Rate, MIDI Record.
- Sequencer special feature: Real time versatile step shifting.

Hardware and Controls

- 26 Soft touch knobs + 27 Buttons
- 88 LED indicators
- 2x20 Character OLED display
- 3 buttons for previewing presets
- 2 knobs acting as Mod-wheel and After-touch
- 896 Sound programs, (384 Factory presets, 512 User presets)

Ins and Out

- Stereo audio output: 2x 1/4" TRS jacks (Balanced)
- External audio input: 1x 1/4" TRS jack (Unbalanced)
- Headphone Out: 1x 1/4" TRS stereo jack
- CV/Gate input/output: 1x 1/4" TRS jack
- MIDI In, MIDI Out
- USB port (Only For OS Update)
- DC Power input

Physical Specs

- Rigid aluminum enclosure + wooden side panels
- Dimensions: 12.9" L x 6.5" W x 1.9" H (32.8 cm x 16.7 cm x 5 cm)
- Weight: ~2.8 lb (1.3 kg)
* Includes universal power supply for 110V – 240V AC operation (12 VDC, 1A)
